Product details
- Intel Xeon 6 SoC
- 2x 100G QSFP56
Overview
The IAC-PTL301A, powered by Intel® Xeon® 6 SoC, enables hardware acceleration for networking and AI workloads, delivering exceptional performance and efficiency tailored to the needs of telecom operators.
Use Cases
Specifications
| Platform | |
| Form Factor | FHFL PCIe Car |
| Processor Options | Intel® Xeon® 6 SoC Processor |
| CPU Socket | Onboard |
| Security Acceleration | Intel® QuickAssist Technology |
| BIOS | AMI SPI Flash BIOS |
| System Memory | |
| Technology | 2CH ECC DDR5, Memory Down, 4800MT/s |
| Max. Capacity | 32GB |
| Socket | N/A |
| Networking | |
| Ethernet Ports | 1x GbE RJ45 & 2x 100G QSFP56 |
| Bypass | N/A |
| NIC Module Slot | N/A |
| LOM | |
| IO Interface | 1x GbE RJ-45 Shared With MGMT |
| OPMA Slot | N/A |
| I/O Interface | |
| Reset Button | 1 |
| LED | N/A |
| Power Button | N/A |
| Console | 1x Mini USB |
| USB | 1 x USB Type C |
| LCD Module | N/A |
| Display | N/A |
| Power Input | 8-pin ATX Power Connector For 12V |
| Storage | |
| HDD/SSD Support | N/A |
| Onboard Slots | 128GB NVME (PCIE*2) |
| Expansion | |
| PCIe | N/A |
| Mini-PCIe | N/A |
| SIM Card Slot | N/A |
| Miscellaneous | |
| Watchdog | Yes |
| Internal RTC with Li Battery | Yes |
| TPM | Onboard |
| Cooling | |
| Processor | Passive CPU Heatsink |
| System | N/A |
| Environmental Parameters | |
| Temperature | 0~40ºC Operating -40~70ºC Non-Operating |
| Humidity (RH) | 5~90% Operating 5~95% Non-Operating |
| System Dimensions | |
| (WxDxH) | TBD |
| Weight | 2kg |
| Package Dimensions | |
| (WxDxH) | TBD |
| Weight | TBD |
| Power | |
| Type / Watts | N/A |
| Input | N/A |
| Certification | |
| Approvals and Compliance | RoHS, UL |
Order Information
| IAC-PTL301A | Intel Xeon 6 SoC, 1x GbE RJ45, 2x 100G QSFP56 |
All product specifications are subject to change without prior notice
